Key Features
• 12 Numeric Keypads with Back Lighting
• Wall Mount (US, EU, Asian Gang Box Size)
• Reverse Polarity Protection
• Read Range : IDC80 / IDC170 Up to 4 inch (10cm)
• Operation Mode (RF, PIN, RF+PIN)
• 125KHz[PSK Modulation] Proximity / PIN Reader
• User Format Available
• Output Format
- Card : 26Bit Wiegand (Default) / RS232 and ABA Track II (Optional)
- Keypad : 26Bit Wiegand, 4/8Bit Burst for PIN Output Format Selectable
• 12 Numeric Keypads with Back Lighting
• External LED Control
• External Buzzer Control
• Tamper Switch
• Wall Mount (US, EU, Asian Gang Box Size)
• Reverse Polarity Protection
• Options : 3ea of External LED Control, Supervisory Signal
• Compatible Controller : All IDTECK Controllers
